Specification：
| Model |
2000 |
2300 |
2500 |
2700 |
3000 |
| Machine dimension (mm) |
2600 50 4 00 |
2900 50 4 00 |
3200 50 4 00 |
3400 00 4 00 |
3700 00 4 00 |
| Power (KW) |
4 |
4 |
4 |
4 |
5.5 |
| Max slitting width (mm) |
1800 |
2100 |
2300 |
2500 |
2800 |
| Min slitting width (mm) |
140 |
140 |
| Min slitting length (mm) |
435 |
460 |
| Min scoring width (mm) |
80 |
80 |
| Scoring height (mm) |
0-10 |
0-12 |
| Blade (mm) |
Φ 200×122×1.2 |
Φ200 × 122 × 1.2 |
| Blade & Scoring Composed Type |
Four blade Six Scoring/ Five Blades Eight scoring |
Character：
●Adopt front-scoring feeding, back double rubber roll leading paper, paperboard running steady.
●Adopt electric adjust blade distance, pneumatic lock. Improve whole machine degree oi automation, easy to operate and high precision, save time arid labor to adjust.
●Slitting Part: adopt high quality tungsten steel blade, sharp and long work-life, slice more tidy, non-pressing and non-burr.
●Scoring Part: adopt 5 points scoring, scoring distance in-phase adjust, blazonry and easy to bend the carton sheet.
●Grinding Part: adopt automatic and manual two kinds pneumatic grinding type, it could be grinding when working, improve work efficiency.
● Adopt China famous brand or imported electric element, dependable pedormance.
|
